XZG810
The XZG810 is a desktop barcode and QR code scanner designed for fixed workstation deployment. Equipped with smart sensing technology, it supports fully hands‑free operation by instantly and automatically reading codes as soon as an item enters its field of view. This eliminates repetitive manual scanning motions for operators, significantly enhancing efficiency in high‑volume batch processing environments—such as retail point‑of‑sale (POS) systems, supermarket checkout counters, logistics and parcel sorting hubs, warehouse inventory management, and industrial assembly line tracking.
With superior reading performance, the scanner accurately decodes a wide range of complex and challenging codes, including damaged paper labels, crumpled barcodes, and digital screen‑displayed QR codes. Its plug‑and‑play design enables seamless integration into existing systems without requiring complex configuration, making it an ideal solution for boosting productivity, reducing operator fatigue, and lowering labor intensity across retail, logistics, warehousing, and manufacturing applications.
Recommended applications:
Retail & Catering
Manufacturing
Office & Asset Management
Library & Archives
Healthcare
Warehousing, Logistics & Supply Chain
Specification
| Image Sensor | full field CMOS |
|---|---|
| Resolution | 1280*800 |
| Communication Interface | USB(HID,CDC,HIDPOS),RS232 |
| 2D Code Support | QR, MicroQR, PDF417, MicroPDF, DataMatrix, Aztex, Maxicode, hanxin, etc. |
| 1D Code Support | Code 128, EAN-13, EAN-8, Code 39, UPC-A, UPC-E, Codabar, Interleaved 2 of 5, ITF-6, ITF-14, ISBN, Code 93, UCC/EAN-128, GS1 Databar, Matrix 2 of 5, Standard 2 of 5, Plessey, MSI-Plessey, etc. |
| Reading Accuracy | 4mil |
| Illuminator | Red LED |
| Field of View | 64°(H), 40°(V) |
| Dimension | W215mm * D160mm * H100mm |
| Weight | 421g |
| Power Consumption | 1w |
| Power Supply | DC 5V |
| Alert | blue LED and buzzer |
| Temperature | operating: -20°C to 50°C, storage:-40°C to 70°C |
